U-Line
U-Line Wine Captain 18" Reversible Hinge Stainless 115v
U-Line Wine Captain 18" Reversible Hinge Stainless 115v
No reviews
Regular price
$5,209.00 USD
Regular price
Sale price
$5,209.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
The 18" 5 Class Wine Refrigerator is designed for discerning wine enthusiasts. It boasts stainless steel construction inside and out, convection cooling for rapid and stable temperature control, and a cutting-edge variable speed compressor. Part of U-Line's 5 Class Collection, it offers a unique full-depth lower interior to maximize storage, adjustable blue and white LED lighting, and U-Adjust™ racks with 19 positions for full extension. Suitable for built-in or freestanding installation, it comes with stainless steel or integrated door options that accommodate custom panels to seamlessly blend with your cabinetry.
FEATURES
- Industry Exclusive: Full-depth lower interior maximizes storage options
- Industry Leading: Variable speed compressor delivers maximum energy efficiency, faster temperature response, and quieter operation
- Convection cooling system provides a quick cool down and consistent temperature
- Stainless steel interior
- Stainless steel cabinet, grille, and accents
- U-Adjust™ Interior: 19 adjustable positions
- Seven removable, full-extension wine racks
- Wine racks accommodate a variety of bottle shapes and sizes and can be configured to store champagne and magnum bottles
- Digital touch pad control
- Temperature range: 33°F to 70°F
- Adjustable bright white or blue LED lighting
- Soft close door with articulating hinges
- Volume of 3.7 cu ft holds up to 35 wine bottles (750 ml)
- Stainless steel handle (7⁄8" diameter)
- Integrated model requires 3⁄4" custom door panel and handle (not supplied by U-Line)
- Field reversible door is shipped right-hand hinged
- Built-in or freestanding
- Four adjustable leveling legs
SPECIFICATIONS
| Amps: Running (115 v) | 1.6 A |
|---|---|
| Capacity: Total Volume (cu ft) | 3.7 cu ft |
| Capacity: Wine Bottle (750 ml) | 35 |
| Control Type | Digital |
| Defrost Type | Automatic |
| Dimensions: Product Depth | 23 7/16" (595mm) |
| Dimensions: Product Height | 33 11/16" (856mm) |
| Dimensions: Product Width | 17 3/4" (450mm) |
| Energy Consumption: Avg. Per Year | 290 kWh |
| Refrigerant Type | R600a |
| Sabbath (Star K Certified) | Yes |
| Shipping Depth | 28.63" (727mm) |
| Shipping Height | 36" (914mm) |
| Shipping Weight | 128 lb (58 kg) |
| Shipping Width | 19.75" (502mm) |
| Temperature Range | 33°F to 70°F |
MODEL SUMMARY
| Model | Voltage / Hz | Finish | Door Swing | Lock | Shipping Weight |
|---|---|---|---|---|---|
| UHWC518-SG01A | 115 V/60 Hz | Stainless Frame | Field Reversible | No | 128 lb (58 kg) |
