U-Line Wine Captain 15" Reversible Hinge Integrated Solid 115v
U-Line Wine Captain 15" Reversible Hinge Integrated Solid 115v
No reviews
Regular price
$2,699.00 USD
Regular price
Sale price
$2,699.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
The 15 1 Class Wine Refrigerator is ideal for wine enthusiasts seeking both style and functionality. Available with stainless steel, black, or integrated door options that accommodate custom panels to blend seamlessly with your cabinetry, this U-Line 1 Class model is engineered to maintain optimal conditions for your wine collection. It fits perfectly into cabinetry or can be used as a freestanding unit, offering versatile installation to suit your space.
FEATURES
- Convection cooling system provides a quick cool down and consistent temperature
- Convection cooling system provides a quick cool down and consistent temperature
- Black interior
- LowE coated, argon gas filled, dual thermopane glass door provides protection from harmful UV Light
- Stainless steel full-wrap door and handle (7/8" diameter)
- Stainless steel grille (stainless model), black metal grille (black and integrated models)
- Five, three-quarter extension, black wine racks
- Wine racks accommodate a variety of bottle shapes and sizes; the fourth and fifth racks allow for larger diameter wine and champagne bottles
- Digital touch pad control
- Temperature range: 34°F to 60°F
- Bright white LED lighting
- Volume of 3 cu ft holds up to 24 wine bottles (750 ml)
- Field reversible door is shipped right-hand hinged
- Built-in or freestanding
- Four adjustable leveling legs
SPECIFICATIONS
Amps: Running (115 v) | 1.2 A |
---|---|
Capacity: Total Volume (cu ft) | 3 cu ft |
Capacity: Wine Bottle (750 ml) | 24 |
Control Type | Digital |
Defrost Type | Automatic |
Dimensions: Product Depth | 22 1/4" (562mm) |
Dimensions: Product Height | 34 1/8" (867mm) |
Dimensions: Product Width | 14 15/16" (379mm) |
Energy Consumption: Avg. Per Year | 285 kWh |
Refrigerant Type | R600a |
Sabbath (Star K Certified) | Yes |
Shipping Depth | 28.5" (724mm) |
Shipping Height | 36" (914mm) |
Shipping Weight | 102 lb (46 kg) |
Shipping Width | 17.13" (435mm) |
Temperature Range | 34°F to 60°F |
MODEL SUMMARY
Model | Voltage / Hz | Finish | Shipping Weight | |
---|---|---|---|---|
UHWC115-IS01A | 115 V/60 Hz | Integrated Solid | 95 lb (43.1 kg) |
DOWNLOADS:
- CAD-2D (DWG)
- CAD-3D (DWG)
- CAD-3D Studio Max (3DS)
- CAD-3D Studio Max (MAX)
- CAD-ArchiCAD (GSM)
- CAD-AutoCAD (DXF)
- CAD-REVIT (RFA)
- CAD-SketchUp (SKP)
- CAD-Wavefront 3D (OBJ)
- Compliance
- Current Product Warranty
- Energuide (Canada)
- Energy Guide (US)
- Quick Start Guide
- Spec Sheet
- User Guide & Service Manual
- Product Warranty
