Summit Appliance Freestanding Black Wine Keg Dispenser Black With Digital Thermostat and Tap Kit
Summit Appliance Freestanding Black Wine Keg Dispenser Black With Digital Thermostat and Tap Kit
Couldn't load pickup availability
Elevate your wine service with Summit's SBC635MWKD, a specialized black wine keg dispenser engineered for the expanding draft wine market. This compact 24" unit features a reversible door and precise digital thermostat maintaining optimal temperatures (33-50°F) for white wines and rosés.
The professional single-tap system accommodates one 1/6 wine keg with additional storage space for a second barrel. Automatic defrost functionality ensures effortless maintenance, allowing you to focus on delivering premium wine service with commercial-grade reliability.
The Summit SBC635MWKD arrives fully equipped for premium wine dispensing, featuring a comprehensive 304-grade stainless steel tap system including tower, faucet, and specialized keg coupler probe. An empty canister is provided, optimally designed for the industry-standard 75% nitrogen/25% CO2 blend that ensures superior wine preservation and service.
The thoughtfully engineered design incorporates a detachable guard rail and drip tray for simplified maintenance, while the included caster set offers mobility when required. This professional-grade unit is specifically configured for versatile freestanding installation in commercial environments.
FEATURES
5.6 cu.ft. interior allows you to store an extra 1/6 size wine keg inside
Ships with a complete wine tap kit that includes a dispenser tower, regulator, and all the connection equipment you need to serve from a 1/6 wine keg or disposable wine keg
Reduced user maintenance with auto defrost operation
Electronic controls ensure easy temperature management, with an external readout in Celsius or Fahrenheit
Operates between 33º and 50ºF to keep a variety of white and blush wine chilled
Canister is best suited for a 75% nitrogen/25% CO2 mixture
User-reversible door swing for added flexibility
To make the dispenser portable, install this set of 2 1/2" high locking casters
Attractive chrome guard rail helps to reduce spills and neaten service
Interior includes steel cover to protect the floor when loading kegs
Kit includes everything you need to keep your wine kegerator clean
Removable drip tray catches spills to help contain the mess
Allows the unit to be used freestanding
Environmentally friendly design without ozone-damaging chemicals
Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Nominal Height | 34.0" (86 cm) |
| Height of Cabinet | 33.5" (85 cm) |
| Nominal Width | 24.0" (61 cm) |
| Width | 23.63" (60 cm) |
| Width with Door Open | 25.0" (64 cm) |
| Nominal Depth | 25.0" (64 cm) |
| Depth | 25.0" (64 cm) |
| Depth with door at 90° | 47.0" (119 cm) |
| Capacity | 5.6 cu.ft. (159 L) |
| Defrost Type | Automatic |
| Door | Black |
| Cabinet | Black |
| US Electrical Safety | UL |
| Canadian Electrical Safety | ULC |
| Amps | 0.86 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 80.0 lbs. (36 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101056067 |
|
Kegerator
|
|
| Door Swing | RHD |
| Reversible | Yes |
| Tap Kit | Yes |
| Height with Tap | 49.0" (124 cm) |
| Number of Taps | 1 |
| Thermostat Type | Digital |
| Refrigerant | R600a |
| Refrigerant Amount | 1.13 oz. |
| High Side PSI | 250.0 |
| Low Side PSI | 110.0 |
| Inter Height | 28.0" (71 cm) |
| Interior Width | 20.5" (52 cm) |
| Interior Depth | 19.0" (48 cm) |
| Compressor Step Height | 8.25" (21 cm) |
| Wheel Qty | 4 |
| Temperature Range | 33º to 50º F |
AVAILABLE UPGRADES
| Exterior | |
| LHD - Left hand door swing | Latch - Factory-installed door latch requires manual release to open unit |
DOWNLOADS
| BROCHURE w/ DRAWINGS |
SBC635MWKD.pdf |
| TECHNICAL DRAWING (.dwg) | MSDS_R600a_C.pdf |
| REVIT MODEL | SBC635MWKD_manual.pdf |
