Create ice easily with the Summit Clear Icemaker. Its compact size makes it perfect for any kitchen or bar. With a built-in stainless steel frame, the door can be customized with matching panels. The auto defrost feature adds convenience, while its ADA compliance ensures easy access for all. (Panel not included.)
Get ready to be the ultimate ice-making machine with the Summit Appliance Built-In 50 lb. Clear Icemaker! With automatic defrost and front-breathing cooling, this unit is easy to maintain and versatile for built-in or freestanding use. Make up to 50lbs of clear cube-shaped ice and store up to 25lbs for all your chilling needs. NSF and ENERGY STAR certified, this icemaker is perfect for commercial use.
FEATURES
Efficient performance for commercial use
32 3/8" height fits under lower ADA compliant counters
NSF listed for use in commercial establishments
Internal pump allows more flexibility in placing the unit
Make the best use of space by installing your appliance under the counter
Stainless steel door frame accepts full overlay panels to match adjacent cabinetry (panel size: 27 7/8" H x14 5/8" W and at least 3/4" thick; maximum weight: 10 lbs.)
Clear cubes offer the perfect cooling of your beverages; NOTE: ice is produced in sheets and can easily be broken into cubes using the provided scoop
Reduced maintenance with auto defrost system
Ice stays frozen longer inside this cold-protected bin
Allows the unit to be used freestanding
Environmentally friendly design with no ozone-damaging chemicals
Complies with California Health and Safety Code 116876 lead leaching requirements per NSF NSF/ANSI/CAN 61-2022 standard, as well as with lead content requirements for ‘lead free’ plumbing as defined by California, Vermont, Maryland, and Louisiana state laws and the U.S. Safe Drinking Water Act Section 1417(d) per NSF/ANSI/CAN 372-2022 standard
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Height of Cabinet | 32.38" (82 cm) |
| Width | 14.5" (37 cm) |
| Depth | 23.5" (60 cm) |
| Defrost Type | Automatic |
| Door | Panel-Ready |
| Cabinet | Black |
| US Electrical Safety | UL |
| Canadian Electrical Safety | ULC |
| Sanitation | NSF |
| Amps | 4.8 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 100.0 lbs. (45 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101029283 |
|
Icemaker
|
|
| Door Swing | LHD |
| Reversible | Factory Reversible |
| Drain Required | Yes |
| Daily Ice Production | 50.0 lbs. (23 kg) |
| Ice Storage Capacity | 25.0 lbs. (11 kg) |
| Ice Shape | Cube |
| Size of Cube | 7/8" x 7/8" x 7/8" |
| Number of Ice Cube Sizes | 1 |
| Fan Type | Exterior |
| Refrigerant Type | R134a |
| Refrigerant Amount | 3.88 oz. |
| High Side PSI | 350.0 |
| Low Side PSI | 130.0 |
| Interior Height | 18.5" (47 cm) |
| Interior Width | 12.0" (30 cm) |
| Interior Depth | 16.0" (41 cm) |
| Level Legs | 4 |
AVAILABLE UPGRADES
| Exterior |
| RHD - Right hand door swing |
DOWNLOADS
| BROCHURE w/ DRAWINGS | |
| USE & CARE | IF_Instructions_-_General.pdf |
| USE & CARE | |
| REVIT MODEL |
