Summit Appliance Black Ice & Water Dispenser
Summit Appliance Black Ice & Water Dispenser
Couldn't load pickup availability
Introducing the Summit Appliance Black Ice & Water Dispenser - the ultimate in convenience. The AIWD160 is ETL-S listed to NSF-12 commercial standards. With a slim width of under 14 inches, this dispenser fits perfectly on standard counters. It can produce up to 160 pounds of ice per day, and offers three dispenser functions - ice, water, or ice+water. The illuminated display adds an extra touch of ease and control. Quench your thirst in style!
Satisfy your thirst with the Summit Appliance Black Ice & Water Dispenser! Adjustable legs make it perfect for any height, while the sleek stainless steel front and black dispenser panel elevate any space. Easy cleaning with a removable tray and sealed back, plus UV lighting and top ventilation. Just make sure to drain below.
Satisfy thirst and ice cravings with the Summit Appliance Black Ice & Water Dispenser. Perfect for hospitals, break rooms, and more, this compact yet powerful machine delivers both ice and water with style. Plus, upgrade with a water filter for peak performance. Quench thirst with the Accucold ice & water line!
FEATURES
Full capacity tabletop ice and water dispenser ideal for break rooms, nursing stations, lobbies, and more
ETL-S listed to NSF-12 commercial standards
Makes it the perfect fit for countertops and similar surfaces, with a 17.5" depth from the rear to front legs
Adjustable legs for added convenience
Large capacity productivity capable of 160 lbs. of ice in a day cycle
Sleek design in black and stainless steel to complement break rooms, patient care areas, office counters, and more
Produces nugget ice which is slow-melting and easy to chew
Save-spacing back allows unit to be flush with the wall, as well as makes cleaning the exterior unit more efficient
Provides an energy efficient, water-saving method to keep the unit cool
Dispenser includes built-in UV lighting, as studies have shown this to be an effective tool for eliminating the growth of bacteria
Provides easy, quick access to water and power supplies
Cost-efficient drainage system
Illuminated display panel for easy use between dispenser functions
Can be removed for fast and efficient cleaning.
Stores up to 5.3 pounds of nugget ice a day
Complies with California Health and Safety Code 116876 lead leaching requirements per NSF NSF/ANSI/CAN 61-2022 standard, as well as with lead content requirements for ‘lead free’ plumbing as defined by California, Vermont, Maryland, and Louisiana state laws and the U.S. Safe Drinking Water Act Section 1417(d) per NSF/ANSI/CAN 372-2022 standard
SPECIFICATIONS
Overview
|
|
---|---|
Height of Cabinet | 24.75" (63 cm) |
Width | 13.75" (35 cm) |
Depth | 24.0" (61 cm) |
Door | Black/SS |
Cabinet | Stainless Steel |
US Electrical Safety | UL |
Canadian Electrical Safety | ULC |
Sanitation | ETL-S |
Amps | 2.8 |
Voltage/Frequency | 115 V AC/60 Hz |
Weight | 106.0 lbs. (48 kg) |
Parts & Labor Warranty | 1 Year |
Compressor Warranty | 5 Years |
UPC | 761101086170 |
Icemaker
|
|
Height Adjustable | Yes |
Drain Required | Yes |
Daily Ice Production | 160.0 lbs. (73 kg) |
Ice Storage Capacity | 5.3 lbs. (2 kg) |
Ice Shape | Nugget |
Number of Ice Cube Sizes | 1 |
Refrigerant Type | R134a |
Refrigerant Amount | 6.35 oz. |
High Side PSI | 250.0 |
Low Side PSI | 150.0 |
Level Legs | 4 |
DOWNLOADS
BROCHURE w/ DRAWINGS |
AIWD160.pdf |
TECHNICAL DRAWING (.dwg) | AIWD160_Technical_Drawing.dwg |
USE & CARE | |
ASSEMBLY DRAWING | |
REVIT MODEL |
