Summit Appliance 7 Bottle 6" Wide Built-In Wine Cellar, ADA Height (Panel Not Included)

Enhance your kitchen, wet bar, or limited space setting with Summit's shallow-depth series of built-in undercounter refrigeration. Our SDHW1532 model is a 15"wide, 18" deep, single-zone wine cellar perfect for small spaces.

With a 34" height, it's designed to fit standard undercounter areas. The front-breathing system allows for easy built-in installation, while the fully finished black cabinet allows for freestanding use. The seamless stainless steel trim and reversible double pane tempered glass door create a sleek, professional look, and the unit also comes with a stainless steel handle.

For added convenience and security, a lock is located in the kickplate. The inside is constructed with durable stainless steel and white LED lighting in the side walls provides excellent display conditions, with dimmable levels for customizable presentation.

The angled digital control panel allows for temperature adjustments between 41º and 68ºF, making it perfect for storing red, white, or sparkling.

Key features include an open-door alarm, high-temperature alarm, and Sabbath mode setting that turns off some electrical elements for up to 96 hours during observances. The SDHW1532, ETL-S listed to NSF-7 commercial standards, can also be utilized in a residential setting. With its luxurious design, user-friendly features, and unusually compact depth, this unit offers exceptional value for various environments.

Complete your collection by pairing it with our SDHW1533 beverage center. Other 18" deep options are available in  15", 19", and 24"  widths, including outdoor refrigerators, refrigerator drawers, and more. For a panel-ready version, refer to model SDHW1532PNR.

NOTE: The interior can accommodate up to 18 Bordeaux-style bottles. Due to the unit's shallow depth, we recommend loading the bottles with the cork facing the rear for the best fit. Wider Burgundy bottles can also fit on most shelves, but loading capacity may vary.



FEATURES

15” Wide Wine Cellar

Single zone wine cooler for residential or commercial storage

18” Depth

Unique 18” shallow depth is ideal for wet bars, island kitchens, and other undercounter areas with limited footprint space

Built-in capable

Front-breathing design lets you make the best use of space by installing your appliance under the counter

Commercially approved

ETL-S listed to NSF-7 Standards and meets UL-471 for use in commercial establishments

Double pane tempered glass door

Elegant design offers a clear but protected view of your interior

Seamless stainless steel door trim

Glass is framed by with a flush one-piece stainless steel trim for an elevated look

Fully articulating European style hinge

Smoother opening and a better fit with an integrated European hinge

Factory installed lock

Keyed lock for a secure interior (2 keys included)

Professional handle

Stainless steel handle completes the look

Commercial wine shelving

Removable steel shelves in a black finish with stainless steel trim for an elegant but modern look

Stainless steel interior

Walls and floor are constructed from stainless steel for added strength and easy cleanup

Digital controls

Easy-to-use digital controls allow for precise temperature settings, which is crucial for maintaining the ideal storage temperature

Ideal temperature range

The unit's temperature range of 41º to 68ºF is ideal for red, white, or sparkling wine bottles

Open door alarm

Alarm sounds if the door is left open for more than 60 seconds

High/low temperature alarm

Audible alarm sounds if the interior temperature rises out of set range

Frost-free operation

No-frost operation for minimum user maintenance

Angled thermostat

Thermostat’s unique and ergonomic position allows for more accessible temperature readings with zero bending required

Dimmable LED light

Efficient and attractive presentation with white LED lighting strips located on each side of the cabinet that can be adjusted between three levels of brightness

Temperature memory function

Unit will retain its last settings when power is restored in the event of power loss

Sabbath mode

Optional setting lets you disable the lighting and alarm for up to 96 hours

Internal fan

Fan-forced cooling ensures fast temperature recovery and that the unit is evenly cooled from top to bottom

Fully finished black cabinet

Allows the unit to be used freestanding

Sealed back

Space-saving design with no exposed coils that offers easier cleanability

Right angle plug

Design allows you to plug the unit in flush against the wall socket with no need to add extra depth

Reversible door

User-reversible door swing for added flexibility to best accommodate your setting

Full capacity

18-bottle capacity with five gliding shelves that can each hold up to 6 bottles, and a floor shelf to hold up to 3 bottles in a horizontal configuration (NOTE: capacity may vary depending on specific bottle style)

Quiet operation

Runs under 34 dB for a quiet performance that won't interrupt your conversation

100% CFC free

Environmentally friendly design with no ozone-damaging chemicals

CARB compliant

Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

SPECIFICATIONS

Overview
Height of Cabinet	33.75” (86 cm)
Width	14.75” (37 cm)
Depth	18.0” (46 cm)
Depth with Handle	19.75” (50 cm)
Depth with door at 90°	32.63” (83 cm)
Capacity	1.8 cu.ft. (51 L)
Bottles	18 bottles
Defrost Type	Frost-Free
Door	Glass
Cabinet	Black
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Sanitation	ETL-S
Amps	1.0
Voltage/Frequency	115 V AC/60 Hz
Weight	88.0 lbs. (40 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
UPC	761101106335
Wine Cellar
Number of Zones	1
Door Swing	RHD
Reversible	Yes
Adjustable Shelves	Yes
Shelf Type	Steel
Shelf Qty	6
Thermostat Type	Digital
Interior Light	Yes
Fan Type	Interior and Exterior
Refrigerant Type	R600a
Refrigerant Amount	0.64 oz.
High Side PSI	270.0
Low Side PSI	105.0
Interior Height 1	26.0” (66 cm)
Interior Width 1	10.63” (27 cm)
Interior Depth 1	12.25” (31 cm)
Compressor Step Height	3.75” (10 cm)
Compressor Step Width	10.63” (27 cm)
Compressor Step Depth	5.0” (13 cm)
Temperature Range	41°F to 68°F
Sabbath Mode	Yes
Sound Level	33.3 dB



AVAILABLE UPGRADES



Door

T1S Door Tint  T4 Door Tint T3 Door Tint T2 Door Tint T1 Door Tint

Exterior

LHD - Left hand door swing
