Elevate the style of any undercounter space with Summit's SWC007. This 6 inch wide wine cellar is fully equipped with convenient features for the user.
Expertly designed for built-in installation, the SWC007 boasts a front-breathing compressor-based cooling system. The durable stainless steel trimmed glass door features a sleek pro style handle and is conveniently reversible for versatile placement options. With a stylish jet black exterior finish, this unit is sure to complement any space. Its sealed back and right angle plug make it a breeze to install flush with cabinetry. This compact unit stands at just 32 1/4 inches, making it perfect for fitting under most ADA compliant counters. Additionally, we provide a kickplate extender and leveling legs that allow for an extra 2 1/2 inch lift, ensuring a seamless fit under standard countertops.
The SWC007 boasts a digital thermostat with intuitive touch controls and a temperature display that can be toggled between Celsius or Fahrenheit with just one button press. Seven spacious slots make storing wine bottles a breeze, plus a sloped floor slot accommodates opened bottles with ease. This unit also has an open door and high temperature alarm for optimal wine storage, and a Sabbath mode option for disabling features during periods of observance.
With its attractive design and innovative size, the SWC007 is the perfect way to finish any kitchen design.
FEATURES
Perfectly sized to complete any extra undercounter space
Make the best use of space by installing your appliance under the counter
Sized at 32 1/4" high to fit under most lower ADA compliant counters
Meets UL-471 commercial standards
Leveling legs can be adjusted to raise the height up to 34.25" for an appropriate fit under standard counters
Provides a full display of your stored collection with a heat-safe double tempered design
Electronic controls for precise temperature management
Interior can hold up to 7 Bordeaux style bottles. Most wider Burgundy style bottles fit as well
The floor slight is slightly angled, allowing you store bottles that have been uncorked at a gentle tilt
Temperature readout can be shown in Celsius or Fahrenheit
Provides an attractive and efficient bottle display
Reduced maintenance and steady temperature performance
Interior fan helps to ensure the temperature is evenly distributed
Stainless steel look for added elegance
User-reversible door swing allows you to easily adjust to better accommodate your setting
Audible alarm will sound if the door is left ajar for over 60 seconds
If the interior temperature becomes too warm, an audible alarm will sound and the temperature display will flash until the proper temperature is restored
Optional setting lets you disable the lighting and alarm for up to 48 hours
Unit will retain last temperature settings in the event of a power failure
Flat design offers added space savings by requiring no extra depth to plug the unit in
Space saving design with easier cleanability
Includes an extra kickplate to cover up the leveling legs if the unit's height is raised
Runs at under 34 dB for a quiet performance in any setting
Compressor-based operation to ensure reliable temperature performance
Environmentally friendly design with no ozone-damaging chemicals
Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Height of Cabinet | 32.25" (82 cm) |
| Width | 5.88" (15 cm) |
| Depth | 20.75" (53 cm) |
| Depth with Handle | 22.38" (57 cm) |
| Depth with door at 90° | 25.5" (65 cm) |
| Bottles | 7 bottles |
| Defrost Type | Automatic |
| Door | Glass |
| Cabinet | Black |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 1.0 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 40.0 lbs. (18 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101056319 |
|
Wine Cellar
|
|
| Number of Zones | 1 |
| Door Swing | RHD |
| Reversible | Yes |
| Height Adjustable | Yes |
| Thermostat Type | Digital |
| Interior Light | Yes |
| Fan Type | Interior and Exterior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 0.57 oz. |
| High Side PSI | 270.0 |
| Low Side PSI | 105.0 |
| Interior Height 1 | 25.75" (65 cm) |
| Interior Width 1 | 3.5" (9 cm) |
| Interior Depth 1 | 14.25" (36 cm) |
| Compressor Step Width | 3.5" (9 cm) |
| Compressor Step Depth | 5.0" (13 cm) |
| Level Legs | 4 |
| Temperature Range | 41 to 72ºF |
| Sabbath Mode | Yes |
| Sound Level | 33.8 dB |
AVAILABLE UPGRADES
| Exterior | LHD - Left-hand door swing |
| Door |
| T3 Door Tint | T1S Door Tint |
| T4 Door Tint | T2 Door Tint |
| T1 Door Tint |
DOWNLOADS
| BROCHURE w/ DRAWINGS | SWC007.pdf |
| USE & CARE | |
| TECHNICAL DRAWING (.dwg) |
