The built-in undercounter wine cellars from SUMMIT provide top-notch storage that combines ease of use with a sophisticated design.
Designed for built-in installation under lower ADA compliant counters, the Summit Appliance SWC3668 wine cellar is just under 32" high and 36" wide. Its sleek and modern look is completed by two seamless stainless steel trimmed glass doors with a unique French door swing, along with factory installed locks for added security and professional handles. Additionally, the fully finished black cabinet allows for freestanding use.
This wine cellar includes two individual zones equipped with digital thermostats, allowing for separate temperature control for white and sparkling wines, as well as red wines. The zones each contain five wooden shelves with a sleek jet black finish and stainless steel trim, along with slotted floors to fit champagne bottles. The interior has a maximum capacity of 68 standard 750ml Bordeaux bottles, or can be arranged to hold up to 56 wider "Burgundy" style bottles, often used for Chardonnay and Pinot Noir. Recessed LED lighting provides a visually appealing display for showcasing your wine collection.
With a professional look and innovative design, SUMMIT SWC3668 , SWC3668ADA is a unique addition to any home.
FEATURES
Make the best use of space by installing this unit under the counter and flush with other cabinetry
ADA compliant height
Less than 32" high to fit under lower counters following ADA guidelines for accessibility
ETL-S listed to ANSI-NSF Standard 7 and meets UL-471
Two distinct temperature zones let you store white wine at colder temperature and red wine under warmer conditions
Interior can hold 68 standard 750ml Bordeaux style bottles, or 56 wider Burgundy bottles
Gentle and energy efficient LED lighting offers an elegant view of your collection
Each zone is equipped with electronic temperature controls for easy and intuitive temperature management
Stainless steel trimmed wooden shelves with a jet black finish for a modern look
Sleek stainless steel handles add an elegant touch to any setting
French door swing for a more dramatic presentation
Door trim is completely seamless for a more luxurious look
Keyed locks on both zones offer separate security for interior contents
Reduced user maintenance with automatic defrost
Internal fans ensure both interiors have a consistent temperature from top to bottom
Allows the unit to be used freestanding
Space-saving design that ensures easier cleanup
Environmentally friendly design without ozone-damaging chemicals
Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
SPECIFICATIONS
Overview
|
|
---|---|
Height of Cabinet | 31.5" (80 cm) |
Width | 35.38" (90 cm) |
Depth | 23.5" (60 cm) |
Depth with Handle | 25.25" (64 cm) |
Depth with door at 90° | 39.75" (101 cm) |
Bottles | 68 bottles |
Defrost Type | Automatic |
Door | Glass |
Cabinet | Black |
US Electrical Safety | ETL |
Canadian Electrical Safety | ETL-C |
Sanitation | ETL-S |
Amps | 1.25 |
Voltage/Frequency | 115 V AC/60 Hz |
Weight | 151.0 lbs. (68 kg) |
Parts & Labor Warranty | 1 Year |
Compressor Warranty | 5 Years |
UPC | 761101054940 761101054940 |
Wine Cellar
|
|
Number of Zones | 2 |
Door Swing | French |
Adjustable Shelves | Yes |
Shelf Type | Wood |
Shelf Qty | 10 |
Thermostat Type | Digital |
Interior Light | Yes |
Fan Type | Interior and Exterior |
Refrigerant Type | R600a |
Refrigerant Amount | 1.06 oz. |
High Side PSI | 150.0 |
Low Side PSI | 50.0 |
Interior Height 1 | 23.0" (58 cm) |
Interior Width 1 | 14.0" (36 cm) |
Interior Depth 1 | 18.0" (46 cm) |
Compressor Step Height | 5.0" (13 cm) |
Compressor Step Width | 14.0" (36 cm) |
Compressor Step Depth | 5.0" (13 cm) |
Level Legs | 4 |
Temperature Range | 40 to 72ºF |
Interior Height 2 | 23.0" (58 cm) |
Interior Width 2 | 14.0" (36 cm) |
Interior Depth 2 | 18.0" (46 cm) |
Sound Level | 36.0 dB |
AVAILABLE UPGRADES
Exterior |
SSK - Stainless steel kickplate |
Door |
T3F Door Tint | T1SF Door Tint |
T4F Door Tint | T2F Door Tint |
