Keep your drinks cold and refreshing with Summit's BIM68OS series icemaker. This durable and stylish appliance can be used indoors or outdoors, and features a 304 grade stainless steel exterior that can withstand the elements. With its front-breathing design and customizable door panel, this icemaker is perfect for any space. (Panel not included)
Introducing the Summit Appliance 62 lb. Clear Outdoor Icemaker - your go-to solution for keeping drinks chilled without watering them down. Our weatherproof design is perfect for outdoor use and can also be installed indoors. With a frost-free operation and 62 lbs. of daily ice production, you'll never have to worry about defrosting and always have enough ice. (Panel Not Included)
Chill out with the Summit Appliance 62 lb. Clear Outdoor Icemaker! (Panel Not Included) This professional-grade unit keeps your beverages ice-cold while adding a touch of cool to your outdoor space. Note: Install with care, drain hose and connection equipment not included.
FEATURES
15" wide built-in undercounter icemaker produces 62 lbs. of clear gourmet ice cubes
ETL-S listed to NSF-12 commercial standards for use in foodservice settings
Durable construction for safe installation in outdoor kitchens
Can make up to 62 lbs. in a day cycle, producing 24 cubes in a 30 minute span
Front-breathing design lets you make the best use of space by installing your appliance under the counter
Integrated door frame accepts overlay panels for a customized look (panel size: 29 9/16" H x 14 7/8" W at 3/4" thick)
Door and cabinet are fully wrapped in 304 grade stainless steel for lasting elegance
Gourmet style rounded dice-style ice cubes
No-frost operation for minimum user maintenance
Requires connection to gravity drain
Unit ships RHD but can be ordered with a left hand door swing (option LHD); not field-reversible
Operates with a standard 1/4” OD water supply line
Space-saving design with easier cleanability
Allows the unit to be used freestanding
Environmentally friendly design without ozone-damaging chemicals
Complies with California Health and Safety Code 116876 lead leaching requirements per NSF NSF/ANSI/CAN 61-2022 standard, as well as with lead content requirements for ‘lead free’ plumbing as defined by California, Vermont, Maryland, and Louisiana state laws and the U.S. Safe Drinking Water Act Section 1417(d) per NSF/ANSI/CAN 372-2022 standard
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Height of Cabinet | 33.5" (85 cm) |
| Height to Hinge Cap | 33.63" (85 cm) |
| Width | 14.88" (38 cm) |
| Depth | 22.63" (57 cm) |
| Depth with door at 90° | 37.25" (95 cm) |
| Capacity | 0.98 cu.ft. (28 L) |
| Defrost Type | Frost-Free |
| Door | Panel-Ready |
| Cabinet | Stainless Steel |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Sanitation | ETL-S |
| Amps | 4.0 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 105.0 lbs. (48 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101061801 761101061795 |
|
Icemaker
|
|
| Door Swing | RHD |
| Reversible | Factory Reversible |
| Daily Ice Production | 62.0 lbs. (28 kg) |
| Ice Storage Capacity | 26.0 lbs. (12 kg) |
| Size of Cube | 1 1/4" H x 1 1/8" W x 1 1/8" D |
| Number of Ice Cube Sizes | 1 |
| Fan Type | Exterior |
| Refrigerant Type | R134a |
| Refrigerant Amount | 7.4 oz. |
| High Side PSI | 210.0 |
| Low Side PSI | 102.0 |
| Interior Height | 12.75" (32 cm) |
| Interior Width | 12.75" (32 cm) |
| Interior Depth | 9.25" (23 cm) |
| Level Legs | 4 |
AVAILABLE UPGRADES
| Exterior |
| LHD - Left hand door swing |
DOWNLOADS
| BROCHURE w/ DRAWINGS |
BIM68OSGDRIF.pdf BIM68OSPUMPIF.pdf |
| TECHNICAL DRAWING (.dwg) | BIM68OSPUMPIF_ICE_MAKER__A-C_2018_.dwg |
| USE & CARE | |
| ASSEMBLY DRAWING | |
| REVIT MODEL | |
| USE & CARE |
