The SUMMIT SWC6GBI series offers ETL-S-listed European wine cellars specifically designed for commercial applications.
The SWC6GBLTB has a compact 24" width and depth for easy storage. It's finished in sleek black for standalone placement and features a double-pane tempered glass door for optimal visibility and durability. The brushed stainless steel towel bar handle adds a touch of professionalism, and the lock is conveniently located near the top of the door for quick access.
The SWC6GBLTB has adjustable scalloped shelves that are tailored to securely hold bottles in place. Its white interior enhances visibility and highlights your collection. This unit also features an interior light with an on/off rocker switch conveniently located behind the adjustable dial thermostat.
The SWC6GBLTB is manufactured in Europe and certified ETL-S to NSF-7 standards for commercial purposes. Further options include various handle styles and door tint choices.
This product is primarily optimized for storing white wine, but it can be enhanced with a digital thermostat to provide optimal conditions for red wine as well.
FEATURES
ETL-S is listed to NSF-7 for use in food service establishments
Less than 24" wide to fit tight spaces
Allows the unit to be used freestanding
Display your collection behind a solid glass door trimmed in elegant brushed aluminum for a refined touch
Keyed lock for secure interior, conveniently located at the top of the door
A curved stainless steel handle provides generous room for a comfortable grip
Reduced maintenance with auto defrost system
Fan-forced cooling helps to maintain a more evenly cooled interior
Curved shelves designed for the ideal storage of wine bottles
Sits on top of the compressor and features wire slots ideal for holding bottles on their sides
Illuminate your collection with an interior light controlled by a rocker on/off switch
SUMMIT's original "hidden" evaporator is concealed in the wall so it never touches your fingers or food
Dial thermostat accommodates white wine temperature. If using this model for red wine storage, add a DT digital thermostat upon ordering
Environmentally friendly design
5ºC to 10ºC/41ºF to 50ºF; To reach warmer temperatures, order with our red wine digital thermostat option (10ºC to 18ºC/50ºF to 64ºF range)
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Height of Cabinet | 33.5" (85 cm) |
| Width | 23.63" (60 cm) |
| Depth | 23.5" (60 cm) |
| Capacity | 5.5 cu. ft. (156 L) |
| Bottles | 36 bottles |
| Defrost Type | Automatic |
| Door | Glass |
| Cabinet | Black |
| US Electrical Safety | UL |
| Canadian Electrical Safety | ULC |
| Sanitation | ETL-S |
| Amps | 1.3 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 115.0 lbs. (52 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101004198 |
|
Wine Cellar
|
|
| Number of Zones | 1 |
| Door Swing | RHD |
| Reversible | Factory Reversible |
| Adjustable Shelves | Yes |
| Shelf Type | Scalloped |
| Shelf Qty | 4 |
| Thermostat Type | Dial |
| Interior Light | Yes |
| Fan Type | Interior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 0.67 oz. |
| High Side PSI | 124.0 |
| Low Side PSI | 30.0 |
| Interior Height 1 | 26.0" (66 cm) |
| Interior Width 1 | 20.75" (53 cm) |
| Interior Depth 1 | 17.5" (44 cm) |
| Compressor Step Height | 6.0" (15 cm) |
| Compressor Step Width | 20.75" (53 cm) |
| Compressor Step Depth | 5.0" (13 cm) |
| Condensor Location | Rear of Unit |
AVAILABLE UPGRADES
| Exterior |
| SSK - Stainless steel kickplate | Latch - Factory-installed door latch requires manual release to open unit |
| Alarm/Thermometer - Factory-installed alarm with external temperature readout | CAS3 3" casters |
| SCD - Self-closing door | LHD - Left-hand door swing |
| DT - Digital thermostat | Legs to raise unit height |
| Door |
| T1 Door Tint | T1S Door Tint |
| T2 Door Tint | T3 Door Tint |
| T4 Door Tint |
DOWNLOADS
| BROCHURE w/ DRAWINGS | SWC6GBLTB.pdf |
| USE & CARE | SWC6GBL_BI_ADA_manual.pdf |
