Summit Appliance's line of built-in under-counter wine cellars provides high-quality storage and a user-friendly experience while maintaining an elegant style.
With a width of less than 18 inches, the SWC1840B and SWC1840BCSS are ideal for built-in installation under counters. The black cabinet is fully finished, making it suitable for freestanding use as well. The reversible glass door is accented with a sophisticated stainless steel trim and professional handle and includes a factory-installed lock for enhanced security.
This built-in wine cellar offers the ability to store up to 34 Bordeaux or Burgundy-style bottles, with a slotted floor that can also fit champagne. The jet-black finished wooden shelves slide out for a sleek, modern appearance. Recessed LED lighting provides a sophisticated display, and temperature can be easily controlled with the digital thermostat.
Featuring a sleek form and practical layout, the SWC1840B, and SWC1840BCSS a valuable enhancements to any space.
FEATURES
The versatile interior can store up to 34 standard 750ml Bordeaux style or wider Burgundy style bottles
Make the best use of space by installing your appliance under the counter
ETL-S listed to ANSI-NSF Standard 7 for use in commercial establishments
Provides a full display of stored contents with a heat-safe double-tempered design
Keyed security on the door
Electronic controls for precise temperature management.
Temperature readout can be shown in Celsius or Fahrenheit
Gentle illumination with an on/off switch
5 shelves offer the perfect storage for wine bottles in a classic wooden finish
Reduced maintenance with the convenience of auto defrost
Keep your options flexible with a reversible door that is easy to switch when your arrangement changes
Stainless steel look for added elegance
Allows the unit to be used freestanding
Environmentally friendly design with no ozone-damaging chemicals
Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Height of Cabinet | 34.25" (87 cm) |
| Width | 17.75" (45 cm) |
| Depth | 23.5" (60 cm) |
| Depth with door at 90° | 39.75" (101 cm) |
| Capacity | 3.3 cu. ft. (93 L) |
| Bottles | 34 bottles |
| Defrost Type | Automatic |
| Door | Glass |
| Cabinet | Black |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Sanitation | ETL-S |
| Amps | 1.25 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 95.0 lbs. (43 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101055725 761101056203 |
|
Wine Cellar
|
|
| Number of Zones | 1 |
| Door Swing | RHD |
| Reversible | Yes |
| Shelf Type | Wood |
| Shelf Qty | 5 |
| Thermostat Type | Digital |
| Interior Light | Yes |
| Fan Type | Interior and Exterior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 1.06 oz. |
| High Side PSI | 150.0 |
| Low Side PSI | 50.0 |
| Level Legs | 4 |
| Temperature Range | 41º to 68ºF |
| Sound Level | 33.8 dB |
AVAILABLE UPGRADES
| Exterior | SSK - Stainless steel kickplate | LHD - Left-hand door swing |
| Latch - Factory-installed door latch requires manual release to open unit |
| Door |
| T1 Door Tint | T2 Door Tint |
| T3 Door Tint | T4 Door Tint |
| T1S Door Tint |
DOWNLOADS
| BROCHURE w/ DRAWINGS | |
| TECHNICAL DRAWING (.dwg) | SWC1840WINECELLARA-C2000.dwg |
| SUPPORT | SWC1840B_User_Manual.pdf |
| USE & CARE | SWC1840_Shelving_Guide.pdf |
