Summit Appliance
Summit Appliance 30 inch Wide Built-In Undercounter Dual Zone Wine And Craft Beer Cooler With Locks, Digital Thermostats, And Glass Doors In A French Door Swing
Summit Appliance 30 inch Wide Built-In Undercounter Dual Zone Wine And Craft Beer Cooler With Locks, Digital Thermostats, And Glass Doors In A French Door Swing
Couldn't load pickup availability
SUMMIT's SWBV3067B represents sophisticated beverage storage engineering, offering a 30" wide dual-zone solution for wine and craft beer preservation. Designed for seamless undercounter integration while maintaining versatility for freestanding applications, this premium unit features distinctive French-swing glass doors framed with elegant stainless steel trim.
Security and accessibility converge through factory-installed locks and professional-grade handles on both compartments. The refined aesthetic is completed with a stainless steel kickplate, creating a cohesive design that balances technical functionality with architectural elegance for discerning beverage enthusiasts.
The SWBV3067B features dual independent climate zones with precision digital thermostats, enabling simultaneous optimization for red wine preservation at elevated temperatures alongside cooler conditions for white wines and craft beers. Storage versatility is achieved through a customizable arrangement of six jet-black wooden wine racks complemented by four chrome wire shelves, accommodating diverse bottle configurations according to specific collection requirements.
Integrated recessed LED illumination provides sophisticated display lighting while maintaining energy efficiency. This refrigeration system combines professional aesthetics with technical innovation, creating a distinctive and adaptable solution for discriminating home environments.
FEATURES
ETL-S listed to ANSI-NSF Standard 7 for use in commercial establishments
Make the best use of space by installing this unit under the counter and flush with other cabinetry
Allows the unit to be used freestanding
Two independent zones allow you to store both red and white wine or craft beer at the proper conditions
Gentle and energy efficient LED lighting offers an elegant view of stored items
Each zone is equipped with electronic temperature controls for easy and intuitive temperature management
Includes 6 wooden shelves for bottle storage and 4 flat wire shelves to hold craft beer cans or bottles
Sleek stainless steel handles add an elegant touch to any setting
French door swing offers a modern look, with stainless steel door trim for an added accent
Single-piece door trim offers a more deluxe look
Keyed locks on both zones offer separate security for interior contents
Reduced user maintenance with automatic defrost
Internal fans ensure both interiors have a consistent temperature from top to bottom
Environmentally friendly design without ozone-damaging chemicals
Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Nominal Height | 35.0" (89 cm) |
| Height of Cabinet | 34.38" (87 cm) |
| Nominal Width | 30.0" (76 cm) |
| Width | 29.5" (75 cm) |
| Nominal Depth | 23.0" (58 cm) |
| Depth | 22.5" (57 cm) |
| Depth with Handle | 24.25" (62 cm) |
| Depth with door at 90° | 36.0" (91 cm) |
| Capacity | 5.8 cu.ft. (164 L) |
| Bottles | 33 bottles |
| Defrost Type | Automatic |
| Door | Glass |
| Cabinet | Black |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Sanitation | ETL-S |
| Amps | 1.25 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 132.0 lbs. (60 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101055794 |
|
Wine Cellar
|
|
| Number of Zones | 2 |
| Door Swing | French |
| Adjustable Shelves | Yes |
| Shelf Type | Wire and Wood |
| Shelf Qty | 10 |
| Thermostat Type | Digital |
| Interior Light | Yes |
| Fan Type | Interior and Exterior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 1.06 oz. |
| High Side PSI | 150.0 |
| Low Side PSI | 50.0 |
| Interior Height 1 | 27.38" (70 cm) |
| Interior Width 1 | 11.75" (30 cm) |
| Interior Depth 1 | 17.5" (44 cm) |
| Compressor Step Width | 11.75" (30 cm) |
| Compressor Step Depth | 5.0" (13 cm) |
| Level Legs | 4 |
| Temperature Range | 41 to 64ºF |
| Interior Height 2 | 27.38" (70 cm) |
| Interior Width 2 | 11.75" (30 cm) |
| Interior Depth 2 | 17.5" (44 cm) |
AVAILABLE UPGRADES
| Door | |
| T4F Door Tint | T3F Door Tint |
| T2F Door Tint | T1SF Door Tint |
DOWNLOADS
| BROCHURE w/ DRAWINGS | SWBV3067B.pdf |
| TECHNICAL DRAWING (.dwg) | SWBV3067WINEBEVERAGEA-C2000.dwg |
| REVIT MODEL | QF_Summit_SWBV3067B_Wine_Cellar.rfa |
| USE & CARE | SWC3066B_SWBV3067B_Manual_3-29-2019.pdf |
