The Summit Appliance 12.6 cu.ft 24" Wide Beverage Center (SCR1401, SCR1401LH, SCR1401LHCSS, SCR1401CSS) uses frost-free operation, stainless steel interior walls, and a cantilevered shelving system for minimal user maintenance, improved durability and sanitation, and adaptable storage.
The digital control panel, conveniently located at the top, allows for temperature adjustment without bending down. The readout can be displayed in Celsius or Fahrenheit and includes an audible high-temperature alarm, open door alarm, temperature memory function, and sabbath mode setting.
The SCR1401, SCR1401LH, SCR1401LHCSS, and SCR1401CSS are ETL-S listed to NSF-7 standards, making them suitable for use in commercial settings. Similar options with lower heights are also available for areas with limited space. Explore Summit's commercial product line for more choices.
FEATURES
Design meets UL-471 commercial standards and is ETL-S listed to NSF-7 standards for commercial use
Just 24" wide and deep for an easy fit in any setting
No-frost convenience requires no manual defrosting
Walls are constructed from stainless steel for added strength and easy cleanup
Heat-safe glass door with stainless steel trim offers full display all the way down to the floor
Door will automatically close when left ajar, preventing items from accidentally being left exposed to ambient temperatures
Electronic controls for precise temperature management, with a readout viewable in Celsius or Fahrenheit
Adjustable shelving accommodates virtually any size with convenient cantilevered system
On/off button to illuminate stored products with an attractive and energy efficient glow
Keyed lock for a secure interior (2 keys included)
Internal fan ensures the interior is evenly cooled from top to bottom
Alarm sounds if the interior temperature rises out of suggested range
Attractive design in stainless steel to complete the look
Optional setting lets you disable the lighting and alarm for up to 48 hours
Design allows you to plug the unit in flush against the wall socket with no need to add extra depth
Unit will retain its last settings when power is restored in the event of power loss
Allows the unit to be used freestanding
Flexible design with a front-breathing cooling system to allow built-in installation and a fully finished exterior that also enables safe freestanding use
Environmentally friendly design with no ozone-damaging chemicals
Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Height of Cabinet | 69.75" (177 cm) |
| Width | 23.63" (60 cm) |
| Depth | 23.75" (60 cm) |
| Depth with Handle | 25.63" (65 cm) |
| Depth with door at 90° | 46.75" (119 cm) |
| Capacity | 12.6 cu.ft. (357 L) |
| Defrost Type | Frost-Free |
| Door | Glass |
| Cabinet | Black |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Sanitation | ETL-S |
| Amps | 1.7 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 180.0 lbs. (82 kg) 185.0 lbs. (84 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101059891 761101059907 761101064628 761101063690 |
|
Refrigerator Features
|
|
| Sabbath Mode | Yes |
| Door Swing | RHD |
| Reversible | No |
| Shelf Type | Chrome |
| Shelf Qty | 6 |
| Adjustable Shelves | Yes |
| Thermostat Type | Digital |
| Fan Type | Interior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 1.76oz. |
| High Side PSI | 270.0 |
| Low Side PSI | 105.0 |
| Level Legs Qty | 4 |
| Interior Light | Yes |
| Temperature Range | 36 to 68ºF |
| Sound Level | 35.7 dB |
|
Dimensions
|
|
| Interior Height | 59.75" (152 cm) |
| Interior Width | 20.0" (51 cm) |
| Interior Depth | 16.5" (42 cm) |
| Compressor Step Height | 4.5" (11 cm) |
| Compressor Step Width | 4.5" (11 cm) |
| Compressor Step Depth | 4.5" (11 cm) |
