Summit Appliance 24 inch Wide Built-In Beer Dispenser, ADA Compliant Counters With Dual Tap Kit For Two 1/6 Kegs
Summit Appliance 24 inch Wide Built-In Beer Dispenser, ADA Compliant Counters With Dual Tap Kit For Two 1/6 Kegs
Couldn't load pickup availability
Summit Appliance's 24-inch ADA-compliant beer dispenser combines functionality with accessibility. This European-made unit stands 32 inches high, fitting perfectly under lower ADA counters. The stainless steel cabinet features front-breathing design for built-in or freestanding installation.
The double-pane glass door with top-positioned lock and brushed steel handle offers security and style. Complete with Sankey American dual tap kit, guard rail, and removable drip tray, this dispenser accommodates two 1/6 kegs. Interior features include automatic defrost, seamless design, stainless steel floor, interior lighting, and integrated CO2 tank storage. ETL-S listed to NSF-7 commercial standards.
Sized at 32 inches high (32.25 to hinge cap) for installation under lower ADA compliant counters
ETL-S listed to NSF-7 commercial standards and meets UL-471 for use in foodservice settings
Front-breathing design allows fully recessed installation under counters
Includes a 5 lb. CO2 tank and regulator, dual tap draft arm, Sankey American tap, connection hardware, and cleaning kit
Twin draft tower allows you to serve from two 1/6 (sixtel) sized kegs
Heat resistant design provides clear view to promote impulse buys
Exterior features a wrapped stainless steel finish for lasting durability in busy commercial settings
Curved towel bar style handle in brushed stainless steel
Keyed lock conveniently located towards the top of the door for added security (2 keys included)
Interior dial thermostat ensures easy temperature management
No-frost operation for minimum user maintenance
Removable two-piece drip tray included for added convenience
Durable railing makes it easier to neaten service
Turn the light on when you need it and off when you're done with a convenient rocker switch
Bracket is installed inside, allowing you to save on depth by keeping the tank behind your kegs
Interior includes steel cover to protect the floor when loading kegs
Easy clean-up with a seamless liner that won't hold a mess in hidden crevices
Cold wall design with hidden evaporator and seamless interior
Unit ships with a right hand door swing. For a left hand version, add option LHD upon order
Allows the unit to be used freestanding
Environmentally friendly design without ozone-damaging chemicals
Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
SPECIFICATIONS
Overview
|
|
---|---|
Nominal Height | 32.0" (81 cm) |
Height of Cabinet | 32.0" (81 cm) |
Height to Hinge Cap | 32.25" (82 cm) |
Nominal Width | 24.0" (61 cm) |
Width | 23.38" (59 cm) |
Nominal Depth | 23.0" (58 cm) |
Depth | 23.0" (58 cm) |
Depth with Handle | 25.5" (65 cm) |
Depth with door at 90° | 44.5" (113 cm) |
Capacity | 5.5 cu.ft. (156 L) |
Defrost Type | Automatic |
Door | Glass |
Cabinet | Stainless Steel |
US Electrical Safety | ETL |
Canadian Electrical Safety | ETL-C |
Sanitation | ETL-S |
Amps | 1.8 |
Voltage/Frequency | 115 V AC/60 Hz |
Weight | 110.0 lbs. (50 kg) |
Parts & Labor Warranty | 1 Year |
Compressor Warranty | 5 Years |
UPC | 761101062877 |
Kegerator
|
|
Door Swing | RHD |
Reversible | Factory Reversible |
Height Adjustable | 47.5 |
Tap Kit | Yes |
Number of Taps | 2 |
Thermostat Type | Dial |
Interior Light | Yes |
Fan Type | Exterior |
Refrigerant | R600a |
Refrigerant Amount | 0.67 oz. |
High Side PSI | 124.0 |
Low Side PSI | 30.0 |
Inter Height | 26.0" (66 cm) |
Interior Width | 21.0" (53 cm) |
Interior Depth | 18.0" (46 cm) |
Compressor Step Height | 7.0" (18 cm) |
Compressor Step Width | 21.0" (53 cm) |
Compressor Step Depth | 5.5" (14 cm) |
Temperature Range | 34º to 43ºF |
AVAILABLE UPGRADES
Exterior | |
---|---|
LHD - Left hand door swing | DT - Digital thermostat |
SSK - Stainless steel kickplate | |
Door | |
T1 Door Tint | T1SF Door Tint |
T2 Door Tint | T4 Door Tint |
T1S Door Tint | |
Handle | |
TBC Copper Towel Bar Handle Upgrade |
DOWNLOADS
BROCHURE w/ DRAWINGS |
SBC56GBIADA.pdf |
TECHNICAL DRAWING (.dwg) | SBC56GBIADA_BEER_DISP.__A-C_2010_.dwg |
USE & CARE | SBC58BL_SBC56G_ADA_Kegerators_User_Manual.pdf |
