Summit Appliance 24 inch Commercial Glass Door Built-In ADA Compliant Craft Beer And Wine Refrigerator With Digital Thermostat, Black Cabinet, And Lock
Summit Appliance 24 inch Commercial Glass Door Built-In ADA Compliant Craft Beer And Wine Refrigerator With Digital Thermostat, Black Cabinet, And Lock
Couldn't load pickup availability
SUMMIT's SCR600BGLBIDTPUBADA European Pub Cellar provides an intelligent solution for craft beer storage at optimal temperatures. This ETL-S listed, NSF-7 commercial-grade refrigerator features versatile installation options with its front-breathing design for built-in placement or freestanding use in its finished black cabinet.
The reversible double-pane tempered glass door includes a brushed aluminum frame and conveniently positioned top lock for enhanced security. Specifically dimensioned for installation beneath ADA compliant counters, this unit combines accessibility with professional-grade beer and wine storage capabilities.
The SUMMIT Pub Cellar SCR600BGLBIDTPUBADA features precision temperature control with a digital thermostat preset to 45°F, adjustable between 41-65°F to accommodate diverse beer varieties and wine selections.
This sophisticated unit employs automatic defrost technology with an internal circulation fan ensuring temperature uniformity throughout its 5.5 cu.ft. capacity. Storage flexibility is enhanced by adjustable glass shelves and a removable half-sized wire shelf positioned above the compressor step, ideal for horizontal bottle storage.
The bright white interior amplifies visibility, complemented by a manual rocker-switch controlled interior light. This expertly engineered refrigerator combines optimal dimensions with superior functionality for professional beverage presentation, with optional custom door tinting available for enhanced product protection.
FEATURES
Wide range temperature control lets you manage the interior between 41º and 65ºF for optimum storage of all types of beer
32" height allows installation under lower ADA compliant counters
ETL-S listed to ANSI-NSF Standard 7 for use in commercial establishments
Less than 24 inches wide to fit tight spaces
Front-breathing design allows you to install the unit under counters with minimum clearance
Heat resistant design provides clear view to promote impulse buys
Keyed lock conveniently located towards the top of the door for added security (2 keys included)
Electronic controls for precise temperature management
Reduced user maintenance with automatic defrost
Fan-forced cooling helps to maintain a more evenly cooled interior
Rearrange your refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up
Sits on top of the compressor and features wire slots ideal for holding bottles on their sides
Turn the light on when you need it and off when you're done with a convenient rocker switch
Interior offers more visibility with a brighter look
SUMMIT's original "hidden" evaporator is concealed in the wall for easier cleaning and more efficient cooling
Easy clean-up with a seamless liner that won't hold a mess in hidden crevices
User-reversible door swing offers more flexibility
Allows the unit to be used freestanding
Environmentally friendly design without ozone-damaging chemicals
Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Nominal Height | 32.0" (81 cm) |
| Height of Cabinet | 32.0" (81 cm) |
| Height to Hinge Cap | 32.25" (82 cm) |
| Nominal Width | 24.0" (61 cm) |
| Width | 23.63" (60 cm) |
| Nominal Depth | 24.0" (61 cm) |
| Depth | 23.5" (60 cm) |
| Depth with Handle | 25.5" (65 cm) |
| Depth with door at 90° | 46.0" (117 cm) |
| Capacity | 5.5 cu.ft. (156 L) |
| Defrost Type | Automatic |
| Door | Glass |
| Cabinet | Black |
| US Electrical Safety | UL |
| Canadian Electrical Safety | ULC |
| Sanitation | ETL-S |
| Amps | 1.8 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 100.0 lbs. (45 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101056883 |
|
Refrigerator Features
|
|
| Door Swing | RHD |
| Reversible | Yes |
| Height Adjustable | 1 |
| Shelf Type | Glass |
| Shelf Qty | 4 |
| Adjustable Shelves | Yes |
| Thermostat Type | Digital |
| Fan Type | Interior and Exterior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 0.67oz. |
| High Side PSI | 124.0 |
| Low Side PSI | 30.0 |
| Level Legs Qty | 4 |
| Interior Light | Yes |
| Sound Level | 33.5 dB |
|
Dimensions
|
|
| Interior Height | 26.0" (66 cm) |
| Interior Width | 20.75" (53 cm) |
| Interior Depth | 17.5" (44 cm) |
| Compressor Step Height | 6.0" (15 cm) |
| Compressor Step Width | 20.75" (53 cm) |
| Compressor Step Depth | 5.0" (13 cm) |
AVAILABLE UPGRADES
| Exterior | |
| Latch - Factory-installed door latch requires manual release to open unit | SSK - Stainless steel kickplate |
| LHD - Left hand door swing | CAS3 3" casters |
| Legs to raise unit height | TOPSS |
| CAS1 |
| Door | |
| T1 Door Tint | T1S Door Tint |
| T2 Door Tint | T3 Door Tint |
| T4 Door Tint | STO-Step-To-Open Door Pedal |
| HANDLE | |
| HH | HV |
| TB - Stainless steel towel bar style handle |
DOWNLOADS
| BROCHURE | SCR600BGLBIDTPUBADA.pdf |
| USE & CARE | Pub_Cellar_Manual.pdf |
