Summit Appliance 24 inch Built-In Glass Door Kegerator For Use Under ADA Compliant Counters With Dual Tap Kit For Two 1/6 Kegs
Summit Appliance 24 inch Built-In Glass Door Kegerator For Use Under ADA Compliant Counters With Dual Tap Kit For Two 1/6 Kegs
Couldn't load pickup availability
Summit Appliance's 24-inch Built-In Glass Door Kegerator delivers ADA compliance without sacrificing functionality. This European-made 32-inch high unit fits seamlessly under lower counters while offering versatile installation options with its front-breathing design and finished black cabinet.
Features include a reversible double pane glass door with top-positioned security lock, protective guard rail, and removable stainless steel drip tray. The comprehensive dual tap Sankey American kit comes complete with draft tower, regulator, 5 lb. CO2 tank, and all necessary components to dispense from two 1/6 kegs simultaneously.
The SBC56GBIADA's interior is specifically engineered to accommodate two 1/6 (sixtel) kegs, though it cannot fit a standard half barrel. Maintenance is streamlined with automatic defrost functionality and a seamless interior design that facilitates thorough cleaning. The reinforced stainless steel floor provides exceptional durability during keg loading operations.
Convenient features include an interior light with accessible rocker switch control and an intuitive dial thermostat for precise temperature regulation. Space efficiency is maximized with an internal CO2 tank bracket, eliminating the need for external tank placement. This model meets rigorous commercial standards with ETL-S listing to NSF-7 certification. Summit offers additional ADA compliant kegerator variants with panel-ready or glass door options throughout their comprehensive product line.
Sized at 32 inches high (32.25 to hinge cap) for installation under lower ADA compliant counters
ETL-S listed to NSF-7 commercial standards and meets UL-471 for use in foodservice settings
Front-breathing design allows fully recessed installation under counters
Includes a 5 lb. CO2 tank and regulator, dual tap draft arm, Sankey American tap, and connection hardware
Twin draft tower allows you to serve from two 1/6 (sixtel) sized kegs
Heat resistant design provides clear view to promote impulse buys
Keyed lock conveniently located towards the top of the door for added security (2 keys included)
Interior dial thermostat ensures easy temperature management
No-frost operation for minimum user maintenance
User-reversible door swing allows you to easily adjust to better accommodate your setting
Removable two-piece drip tray included for added convenience
Durable railing makes it easier to neaten service
Turn the light on when you need it and off when you're done with a convenient rocker switch
Bracket is installed inside, allowing you to save on depth by keeping the tank behind your kegs
Interior includes steel cover to protect the floor when loading kegs
Easy clean-up with a seamless liner that won't hold a mess in hidden crevices
Cold wall design with hidden evaporator and seamless interior
Allows the unit to be used freestanding
Environmentally friendly design without ozone-damaging chemicals
Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Nominal Height | 32.0" (81 cm) |
| Height of Cabinet | 32.0" (81 cm) |
| Height to Hinge Cap | 32.25" (82 cm) |
| Nominal Width | 24.0" (61 cm) |
| Width | 23.38" (59 cm) |
| Nominal Depth | 23.0" (58 cm) |
| Depth | 23.0" (58 cm) |
| Depth with Handle | 24.88" (63 cm) |
| Depth with door at 90° | 44.5" (113 cm) |
| Capacity | 5.5 cu.ft. (156 L) |
| Defrost Type | Automatic |
| Door | Glass |
| Cabinet | Black |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Sanitation | ETL-S |
| Amps | 1.8 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 110.0 lbs. (50 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101062846 |
|
Kegerator
|
|
| Door Swing | RHD |
| Reversible | Yes |
| Tap Kit | Yes |
| Height with Tap | 47.5" (121 cm) |
| Number of Taps | 2 |
| Thermostat Type | Dial |
| Interior Light | Yes |
| Fan Type | Exterior |
| Refrigerant | R600a |
| Refrigerant Amount | 0.67 oz. |
| High Side PSI | 124.0 |
| Low Side PSI | 30.0 |
| Inter Height | 26.0" (66 cm) |
| Interior Width | 21.0" (53 cm) |
| Interior Depth | 18.0" (46 cm) |
| Compressor Step Height | 7.0" (18 cm) |
| Compressor Step Width | 21.0" (53 cm) |
| Compressor Step Depth | 5.5" (14 cm) |
| Temperature Range | 34º to 43ºF |
AVAILABLE UPGRADES
| Exterior | |
|---|---|
| LHD - Left hand door swing | DT - Digital thermostat |
| SSK - Stainless steel kickplate | |
| Door | |
| T1 Door Tint | T1SF Door Tint |
| T2 Door Tint | T4 Door Tint |
| T1S Door Tint |
DOWNLOADS
| BROCHURE w/ DRAWINGS |
SBC56GBIADA.pdf |
| TECHNICAL DRAWING (.dwg) | SBC56GBIADA_BEER_DISP.__A-C_2010_.dwg |
| REVIT MODEL | Qf_Summit_SBC56GBIADA_24_inches_Wide_Built-In_Beer_Dispenser__ADA_Compliant.rfa |
| USE & CARE | SBC58BL_SBC56G_ADA_Kegerators_User_Manual.pdf |
