The ALFD24WBVPNR boasts dual temperature zones designed to preserve beverages and wines at their ideal temperatures. Its digital temperature controls allow for effortless management of each compartment, with a display that can switch between Fahrenheit and Celsius. The left side features adjustable glass shelves for spill-proof storage of beverages, with a temperature range of 36 to 43ºF.
On the right, wooden shelves in a sleek black finish provide customizable storage for red or white wines, maintaining temperatures between 41 and 72ºF. The unit also includes energy-saving LED lighting for an appealing presentation. In addition, it is equipped with audible alarms that sound when the doors are open for more than one minute or if the temperature exceeds the recommended range. For observant periods, a Sabbath mode is available to disable certain electrical functions.
Discover the versatile storage options and advanced features of Summit's ALFD24WBVPNR Built-In Wine/Beverage Center, perfect for any under-counter space. Explore our website for more information and other ADA-compliant choices in our line.
FEATURES
Sized at just 32" high for installation under lower ADA-compliant counters
Make the best use of space by installing your appliance under the counter
Leveling legs can raise the unit to up to 33.5" for more standardized counters
Door frames can be customized with an overlay panel to best match your cabinetry style (panel size: 28 1/8" H x 11 3/16" W at 3/4" thick)
Set and adjust two temperature zones separately with easy-to-use digital controls that display the temperature in Celsius or Fahrenheit
Independent zones let you store beverages in the left compartment and wine in the right
Each door includes a keyed lock for optional security
The wine zone includes size adjustable wooden shelves in a modern jet black finish
Spill-proof glass shelves make it easy to store and display bottles and cans in the beverage zone
Attractive and energy-efficient LED lighting offers an elegant presentation
Reduced user maintenance with automatic defrost operation
Internal fans ensure both interiors are evenly cooled from top to bottom
Two side-by-side doors with French door opening
Completes the professional look down to the toe kick
Audibly alerts if the interior temperature rises out of the recommended wine storage range
An audible alarm will sound if the doors are left ajar for over 60 seconds
Allows you to disable certain electrical functions for up to 48 hours for periods of observance
The unit will retain its last settings when power is restored in the event of power loss
The design allows you to plug the unit in flush against the wall socket with no need to add extra depth
Space-saving design with easier cleanability
The door hinge adds no additional height, making it easier to install under a counter
Includes an extra stainless steel kickplate piece to cover the legs if the unit's height is raised
Allows the unit to be used freestanding
The environmentally friendly design does not contain ozone-damaging chemicals
Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Height of Cabinet | 32.0" (81 cm) |
| Width | 23.38" (59 cm) |
| Depth | 22.75" (58 cm) |
| Depth with door at 90° | 33.0" (84 cm) |
| Capacity | 4.6 cu. ft. (130 L) |
| Bottles | 21 bottles |
| Defrost Type | Automatic |
| Door | Glass/Panel-Ready Frame |
| Cabinet | Black |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 1.0 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 105.0 lbs. (48 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101088051 |
|
Wine Cellar
|
|
| Number of Zones | 2 |
| Door Swing | French |
| Reversible | No |
| Height Adjustable | Yes |
| Adjustable Shelves | Yes |
| Shelf Type | Glass and Wood |
| Shelf Qty | 8 |
| Thermostat Type | Digital |
| Interior Light | Yes |
| Fan Type | Interior and Exterior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 1.06 oz. |
| High Side PSI | 270.0 |
| Low Side PSI | 105.0 |
| Interior Height 1 | 25.38" (64 cm) |
| Interior Width 1 | 8.38" (21 cm) |
| Interior Depth 1 | 17.5" (44 cm) |
| Compressor Step Height | 3.5" (9 cm) |
| Compressor Step Width | 8.38" (21 cm) |
| Compressor Step Depth | 5.0" (13 cm) |
| Level Legs | 4 |
| Temperature Range | Beverage zone: 36 to 43°F; Wine zone: 41 to 72ºF |
| Interior Height 2 | 25.38" (64 cm) |
| Interior Width 2 | 8.38" (21 cm) |
| Interior Depth 2 | 17.5" (44 cm) |
