Summit Appliance 18 inch Wide Built-In Beverage Center
Summit Appliance 18 inch Wide Built-In Beverage Center
Couldn't load pickup availability
Summit's 18" wide CL181WBVCSS beverage center delivers commercial-grade storage with ETL-S listing to NSF-7 standards. The versatile unit features front-breathing design for undercounter installation while maintaining freestanding capability with its stainless steel wrapped finish.
Elegant details include seamless stainless trim around tinted double-pane glass, professional handle, and European hinges for precise alignment. Interior presentation is enhanced by strategic white LED side lighting against a black backdrop, while security is ensured via a discreet kickplate lock.
The CL181WBVCSS features three adjustable glass shelves providing spill-proof storage, complemented by a specially slotted floor designed to secure wine bottles. Temperature management is precise with an intuitive digital thermostat offering both Celsius and Fahrenheit display options.
Practical design elements include a reversible door, space-saving right angle plug, and easy-clean sealed back. Commercial environments benefit from the integrated alarm system that alerts to ajar doors or temperature fluctuations. This sophisticated unit delivers reliable beverage storage ideal for hospitality settings including restaurants, bars, hotel lobbies, and waiting areas.
Make the best use of space by installing your appliance under the counter
Heat-safe glass ensures your items are stored safely
One-piece stainless steel door frame offers a luxurious look with no exposed seams or holes
Cabinet is fully wrapped in stainless steel for lasting durability
Electronic controls for precise temperature management
Temperature readout can be shown in Celsius or Fahrenheit
Spill-proof glass shelves make it easy to store and display bottles and cans
Floor is specially slotted to store wine and other bottles safely in place
Unique white lighting located inside the walls offers elegant illumination for the jet black interior
Vertically mounted handle in brushed stainless steel
User-reversible door swing allows for more flexibility in placing the unit
Optional setting lets you disable the lighting and alarm for up to 48 hours
Audibly alerts if the interior temperature is too warm
Audible alarm will sound if the door is left ajar for over 60 seconds
Internal fan ensures the interior is evenly cooled from top to bottom
Reduced maintenance and steady temperature performance
Keyed lock located in the kickplate for optional security
Space saving design with easier cleanability
Unit will retain its last settings when power is restored in the event of power loss
Design allows you to plug the unit in flush against the wall socket with no need to add extra depth
Allows the unit to be used freestanding
Smoother opening and a better fit with an integrated European hinge
ETL-S listed to NSF-7 standards
Environmentally friendly design with no ozone-damaging chemicals
Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Nominal Height | 34.0" (86 cm) |
| Height of Cabinet | 33.75" (86 cm) |
| Nominal Width | 18.0" (46 cm) |
| Width | 17.63" (45 cm) |
| Nominal Depth | 23.0" (58 cm) |
| Depth | 22.75" (58 cm) |
| Depth with Handle | 24.5" (62 cm) |
| Depth with door at 90° | 40.13" (102 cm) |
| Capacity | 2.9 cu.ft. (82 L) |
| Bottles | 34 bottles |
| Defrost Type | Automatic |
| Door | Glass |
| Cabinet | Stainless Steel |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Sanitation | ETL-S |
| Energy Usage/Year | 255.0kWh/year |
| Amps | 1.0 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 90.0 lbs. (41 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101055275 |
|
Refrigerator Features
|
|
| Sabbath Mode | Yes |
| Door Swing | RHD |
| Reversible | Yes |
| Shelf Type | Glass |
| Shelf Qty | 3 |
| Adjustable Shelves | Yes |
| Thermostat Type | Digital |
| Fan Type | Interior and Exterior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 0.85oz. |
| High Side PSI | 270.0 |
| Low Side PSI | 105.0 |
| Interior Light | Yes |
| Temperature Range | 36 to 43ºF |
|
Dimensions
|
|
| Interior Height | 23.5" (60 cm) |
| Interior Width | 14.0" (36 cm) |
| Interior Depth | 16.63" (42 cm) |
| Compressor Step Height | 3.25" (8 cm) |
| Compressor Step Width | 14.0" (36 cm) |
| Compressor Step Depth | 5.5" (14 cm) |
AVAILABLE UPGRADES
| Door |
| T1 Door Tint | T4 Door Tint |
| T2 Door Tint | T3 Door Tint |
| T1S Door Tint |
| Exterior | |
| LHD - Left hand door swing | Latch - Factory-installed door latch requires manual release to open unit |
DOWNLOADS
| BROCHURE |
CL181WBVCSS.pdf |
| USE & CARE | CL181WBV_Manual_3-29-2019.pdf |
| MSDS INFORMATION | R600a_K.pdf |
| ENERGY GUIDE | https://www.summitappliance.com/energy_guide/5277.pdf |
