Introducing the versatile Summit Appliance BIM26 icemaker - designed for built-in or freestanding use. At only 15" wide and 25" tall, it's perfect for kitchen islands, home bars, RVs, and even boat kitchens. With a stainless steel finish and sleek handle, this drain-free icemaker brings convenience and luxury to any space.
Get your ice fix with the Summit Appliance 15 lb. Drain-Free Built-In Icemaker! With a static manual defrost cooling system, ice stays solid longer. No drain needed for flexibility, and pre-installed hose for convenience. Plus, a removable bucket, scoop, and scoop holder included! Produces and stores up to 15 and 12 lbs, respectively.
Get ready to chill in style with the Summit Appliance 15 lb. Drain-Free Built-In Icemaker. Its sleek stainless steel door and black cabinet make it the perfect addition to any undercounter kitchen or home bar. Plus, with its low maintenance design, you'll have more ice and less waste. Check out our other sizes, colors, and options in the full Summit product line.
FEATURES
Built-in capable icemaker designed for kitchen islands, home bars, break rooms, health offices, RVs, and even boat kitchens.
Make the best use of space by installing your icemaker under the counter
Produces 15 lbs of crescent-shaped ice and stores up to 12 lbs
Convenient design allows more flexibility in positioning the unit
Static cooling system helps to keep ice frozen for longer periods of time compared to other systems
User-reversible door swing for flexible placement
Space-saving design with easier cleanability
Operates with a standard 1/4” OD water supply line
Horizontally mounted towel bar style handle in stainless steel
Large ice scoop and holder included for your convenience
Crescent-shaped ice provides a harder and longer-lasting ice
Users can remove the ice bucket for fast and easy cleaning
Ice stays solid longer in this cold-protected bin
Environmentally friendly design without ozone-damaging chemicals
Complies with California Health and Safety Code 116876 lead leaching requirements per NSF NSF/ANSI/CAN 61-2022 standard, as well as with lead content requirements for ‘lead free’ plumbing as defined by California, Vermont, Maryland, and Louisiana state laws and the U.S. Safe Drinking Water Act Section 1417(d) per NSF/ANSI/CAN 372-2022 standard
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Height of Cabinet | 24.5" (62 cm) |
| Height to Hinge Cap | 25.0" (64 cm) |
| Width | 14.88" (38 cm) |
| Width with Door Open | 15.13" (38 cm) |
| Depth | 16.75" (43 cm) |
| Depth with door at 90° | 32.25" (82 cm) |
| Defrost Type | Manual |
| Door | Stainless Steel |
| Cabinet | Black |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 1.2 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 50.0 lbs. (23 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101106601 761101108452 |
|
Icemaker
|
|
| Door Swing | RHD |
| Reversible | Yes |
| Height Adjustable | No |
| Daily Ice Production | 15.0 lbs. (7 kg) |
| Ice Storage Capacity | 12.0 lbs. (5 kg) |
| Ice Shape | Crescent |
| Size of Cube | 7/8" x 7/8" x 2-3/8" |
| Number of Ice Cube Sizes | 1 |
| Refrigerant Type | R600a |
| Refrigerant Amount | 1.69 oz. |
| High Side PSI | 120.0 |
| Low Side PSI | 55.0 |
| Interior Height | 12.25" (31 cm) |
| Interior Width | 11.0" (28 cm) |
| Interior Depth | 12.25" (31 cm) |
| Level Legs | 4 |
AVAILABLE UPGRADES
| Exterior | |
|---|---|
|
DOWNLOADS
| BROCHURE w/ DRAWINGS |
|
| TECHNICAL DRAWING (.dwg) | BIM26_2_.dwg |
| USE & CARE | |
| ASSEMBLY DRAWING |
