FEATURES
ETL-S listed to NSF standards for commercial use
Meets ENERGY STAR standards as a commercial refrigerator
Keyed lock for secure interior
Heat-safe glass door offers full display all the way down to the floor
Durable design brings a professional look to any setting
Energy efficient lighting offers full view of interior
Door will automatically close when left ajar, preventing items from accidentally being exposed to ambient temperatures
Electronic controls for precise temperature management with a readout in Celsius or Fahrenheit
Solid chrome handle with brushed stainless steel look
Rearrange refrigerator space to accommodate all sizes or remove shelves for simple cleanup
Walls are constructed from stainless steel for added strength and easy cleanup
Reduced user maintenance with automatic defrost
Audible alarm will sound if the door is left ajar for over a minute
Optional setting lets you disable the lighting and alarm for up to 48 hours
Flexible design with a front-breathing cooling system to allow built-in installation and a fully finished exterior that also enables safe freestanding use
Environmentally friendly design with no ozone-damaging chemicals
Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Height of Cabinet | 58.38" (148 cm) |
| Width | 23.63" (60 cm) |
| Depth | 22.88" (58 cm) |
| Depth with Handle | 24.0" (61 cm) |
| Depth with door at 90° | 45.0" (114 cm) |
| Capacity | 11.0 cu.ft. (311 L) |
| Defrost Type | Automatic |
| Door | Glass |
| Cabinet | Stainless Steel/ Black |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Sanitation | ETL-S |
| Amps | 1.7 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 150.0 / 141.0 lbs. (68 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101032061 /761101004068 |
|
Refrigerator Features
|
|
| Sabbath Mode | Yes |
| Door Swing | RHD |
| Reversible | No |
| Shelf Type | Chrome |
| Shelf Qty | 4 |
| Adjustable Shelves | Yes |
| Thermostat Type | Digital |
| Fan Type | Interior and Exterior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 1.66oz. |
| High Side PSI | 270.0 |
| Low Side PSI | 105.0 |
| Level Legs Qty | 4 |
| Interior Light | Yes |
| Temperature Range | 36°F to 43°F |
|
Dimensions
|
|
| Interior Height | 50.0" (127 cm) |
| Interior Width | 20.0" (51 cm) |
| Interior Depth | 16.5" (42 cm) |
| Compressor Step Height | 4.75" (12 cm) |
| Compressor Step Width | 20.0" (51 cm) |
| Compressor Step Depth | 4.75" (12 cm) |
AVAILABLE UPGRADES
| Interior | ||||
|---|---|---|---|---|
|
||||
| Door | ||||
|
||||
| Exterior | ||||
|
DOWNLOADS
| BROCHURE w/ DRAWINGS | |
| TECHNICAL DRAWING (.dwg) | SCR1156BEVERAGECENTERA-C2000.dwg SCR1156BEVERAGECENTERA-C2000.dwg |
| USE & CARE | |
| REVIT MODEL |
