Upgrade your kitchen with the Summit BIM26H34 icemaker! Made with 304-grade stainless steel, this undercounter unit offers both built-in and freestanding options. At just under 15" wide, it's perfect for tight spaces and can even fit under ADA-compliant counters. Plus, the included smaller kickplate adds a sleek touch.
Get ready to elevate your ice game with the Summit Appliance 100 lb. Commercial Icemaker. This ADA Compliant machine boasts a stylish stainless steel finish and a user-reversible door, all topped off with a sleek horizontal handle. With a static manual defrost cooling system and optional water filter, this icemaker can churn out 25 lbs of ice daily. And don't worry about installation - the sealed back allows for a more flush fit and the pre-installed connection hose makes it a breeze. Plus, you'll have all the necessary tools with the removable ice bucket, scoop, and holder. Ice just got a whole lot cooler (pun intended).
Make ice fun with Summit's stainless steel icemaker! With low maintenance and ADA-compliance, BIM26H34 keeps plenty of ice on hand. Choose from different sizes, colors, and makes -- all equally efficient. Browse the full line for your perfect pick.
FEATURES
ETL-S listed to NSF-12 commercial standards
Includes a set of 1 1/2" high leveling legs to bring the overall height up to 31 1/2", ideal for fitting under lower counters following ADA guidelines
Produces up to 100 lbs. of clear ice in a day cycle
Included leg set allows you to clean the space below the icemaker
Front-breathing design allows this unit to be installed under counters
Efficient, low noise fan for a quiet performance
Produces clear 1" x 1" dice cubes
Helps maintain great tasting ice. A purification filter is required for operation (1 is included with your initial purchase); To order replacement filters, visit summitappliance.com/filter100
Top lid is on lift-up glides for easy access to the ice bin
Automatic sensor alerts when bin is full and stops ice production to prevent overfill
Removable mesh filter located in the front of the icemaker makes it easy to keep the condenser clean
Auto clean mode allows you to periodically clean the system as needed with a neutral detergent
Interior holds up to 27 lbs. of ice
Ice scoop included for added convenience
Space-saving design with easier cleanability
Durable finish allows the unit to be used freestanding
Extra long pre-installed power cord allows more flexibility in placing the unit
We include a set of 4 1/2" high legs for optional use to raise the height up to 34 1/2"
Gravity drain system
Environmentally friendly design with no ozone-damaging chemicals
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Height of Cabinet | 31.5" (80 cm) |
| Width | 20.5" (52 cm) |
| Depth | 22.25" (57 cm) |
| Defrost Type | Automatic |
| Door | Black |
| Cabinet | Stainless Steel |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Sanitation | ETL-S |
| Amps | 3.75 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 110.0 lbs. (50 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101075709 |
|
Icemaker
|
|
| Door Swing | Lift-Up |
| Height Adjustable | Yes |
| Drain Required | Yes |
| Daily Ice Production | 100.0 lbs. (45 kg) |
| Ice Storage Capacity | 27.0 lbs. (12 kg) |
| Ice Shape | Cube |
| Size of Cube | 1" x 1" |
| Number of Ice Cube Sizes | 1 |
| Fan Type | Exterior |
| Refrigerant Type | R134a |
| Refrigerant Amount | 8.5 oz. |
| High Side PSI | 190.0 |
| Low Side PSI | 133.0 |
| Interior Height | 10.25" (26 cm) |
| Interior Width | 18.0" (46 cm) |
| Interior Depth | 17.0" (43 cm) |
| Level Legs | 4 |
DOWNLOADS
| BROCHURE w/ DRAWINGS | BIM100ADA.pdf |
| TECHNICAL DRAWING (.dwg) | BIM100ADA_ICE_MAKER__A-C_2018___1_.dwg |
| USE & CARE | |
| SUPPORT | |
| SUPPORT | |
| REVIT MODEL |
